B109
High Lumen Efficacy - 115lm/W
Body - Die cast aluminum housing with solvent free powder coating
Diffuser - PMMA polycarbonate pattern lens.
Glowing Wire Test - 850°
Temperature - ta=20 °C ~ ta max=50 °C
Class - Ill
Simple and easy appearance, in line with contemporary aesthetic concept. The product has the structure and appearance design patent. The lamp body adopts high-pressure cast aluminum and aluminum alloy, the surface is coated with outdoor used powder , double anti-corrosion to extend service life. This lawn lamp series uses LED. High efficiency constant current driver, ensure the light source is maximum used.
FIELDS OF APPLICATION
Office & Education, offices, open-plan offices, conference rooms,
conference rooms, reception areas, counters, galleries, hotels,
restaurants, living spaces
IP 20 COB McA Step 3 28V - 0.3mA
8 B 1 0 9 - S - 2 7 - 2 5 - 0 - A
Model B109 |
8 B 1 0 9 - S - 2 7 - 2 5 - 0 - A |
||||
|
Size |
A Ø50 - 45.5H mm |
|
|||
|
Driver |
0 |
1 |
2 |
3 |
4 |
|
Beam Angle |
10° |
25° |
36° |
|
|
|
Kelvin |
30 |
40 |
60 |
||
|
Finishing |
Grey |
Silver |
|
|
|
|
Wattage |
08 |
||||
