E311
High Lumen Efficacy 100lm/W
Body - Die cast aluminum
Diffuser - PMMA Lens
Glowing Wire Test - 850°
Temperature - ta=20 °C ~ ta max=50 °C
Class - Ill
Simple and easy appearance, in line with contemporary aesthetic concept. The product has the structure and appearance design patent. The lamp body adopts high-pressure cast aluminum and aluminum alloy, the surface is coated with outdoor used powder , double anti-corrosion to extend service life. This lawn lamp series uses LED. High efficiency constant current driver, ensure the light source is maximum used.
FIELDS OF APPLICATION
Office & Education, offices, open-plan offices, conference rooms,
conference rooms, reception areas, counters, galleries, hotels,
restaurants, living spaces
IP 44 IK 07 COB McA Step 3 220~240V
2 x 7 E 3 1 1 - W - 3 0 - 1 2 - 0 - A
Model E311 |
2 x 7 E 3 1 1 - W - 3 0 - 1 2 - 0 - A |
||||
|
Size |
A 115 X 115 X 95mm Cutout 95 X 95 |
||||
|
Driver |
0 On/Off |
1 Dali |
2 Dimmable |
3 Phase Dimming |
4 1-10 |
|
Beam Angle |
12° | 24° | 38° |
|
|
|
Kelvin |
30 3000K |
||||
|
Finishing |
White |
|
|||
|
Wattage |
2x7 | 2x13.8 | |||
