K41
Description: Passive Infrared Sensor Operating voltage: DC 5V~24V Output voltage: Equal to input voltage Load current: <5A Static power loss: ≤ 50 uA Delay time: Default setting 18sec(3~350 Seconds is adjustable) Light sensor: yes Light sensitivity: default setting 3lux-6lux, Detecting range: ≤ 110 degrees cone angle, ≤3M-5M Trigger way: continuous triggerin
FIELDS OF APPLICATION
Office & Education, offices, open-plan offices, conference rooms,
conference rooms, reception areas, counters, galleries, hotels,
restaurants, living spaces
IP 20 IK 05 DC 5V~24V
K 4 1 - B - A
Model K41 |
K 4 1 - B - A |
||||
|
Size |
A 36 X 36 X 27mm |
||||
|
Driver |
|||||
|
Beam Angle |
|||||
|
Kelvin |
|||||
|
Finishing |
Black | ||||
|
Wattage |
|||||
