K76
High Lumen Efficacy 100lm/W Body - Extruded LED Aluminum profile Glowing Wire Test - 850° Temperature - ta=20 °C ~ ta max=50 °C Class - III
Flex Led Neon is design is both weather resistant and robust. The Flex Led is available in a range of whites and colours that can be tailored to your installation. The PVC construction is UV and salt water resistant for harsh out door environments, the Flex Led Neon Flex also meets fire safety standards. To complement your installation we also offer a range of accessories.
FIELDS OF APPLICATION
Office & Education, offices, open-plan offices, conference rooms,
conference rooms, reception areas, counters, galleries, hotels,
restaurants, living spaces
IP 67 IK 10 LED McA Step 4 DC 24V
6 K 7 6 - A L U - 3 0 - 1 5 - 0 - A
Model K76 |
6 K 7 6 - A L U - 3 0 - 1 5 - 0 - A |
||||
|
Size |
A 600 X 20.5 X 25.5mm |
B 900 X 20.5 X 25.5mm |
C 1200 X 20.5 X 25.5mm |
||
|
Driver |
0 On/Off |
1 Dali |
2 Dimmable |
3 Phase Dimming |
4 1-10 |
|
Beam Angle |
15° | 30° | 60° | 120° | |
|
Kelvin |
30 3000K |
40 4000K |
50 5000K |
60 6000K |
RGB |
|
Finishing |
Aluminum | ||||
|
Wattage |
06 | 09 | 12 | ||
