O40
High Lumen Efficacy 90lm/W
Body - Metal Core PCB
Diffuser - PMMA Polycarbonate
Structure - Aluminum
Glowing Wire Test - 850°
Temperature - ta=20 °C ~ ta max=50 °C
Simple and easy appearance, in line with contemporary aesthetic concept. The product has the structure and appearance design patent. The lamp body adopts high-pressure cast aluminum and aluminum alloy, the surface is coated with outdoor used powder , double anti-corrosion to extend service life. This lawn lamp series uses LED. High efficiency constant current driver, ensure the light source is maximum used.
FIELDS OF APPLICATION
Decorative garden or street lights to perform maximum output.
IP 66 IK 08 SMD McA Step 3
3 O 4 0 - B - 3 0 - 3 6 0 - L C S - A
Model O40 |
3 O 4 0 - B - 3 0 - 3 6 0 - L C S - A |
||||
|
Size |
A 250 X 250 X 290mm |
B 300 X 300 X 360mm |
|||
|
Driver |
Slide Switch | ||||
|
Beam Angle |
360° | ||||
|
Kelvin |
27 2700K |
30 3000K |
40 4000K |
50 5000K |
60 6000K |
|
Finishing |
White | Dark Grey | Black |
|
|
|
Wattage |
03 | 05 | |||
