S04
High Lumen Efficacy 150lm/W Body - Die Cast Aluminum Diffuser - PMMA polycarbonate shock proof Glowing Wire Test - 850° Temperature - ta=20 °C ~ ta max=50 °C Class - III
Simple and easy appearance, in line with contemporary aesthetic concept. The product has the structure and appearance design patent. The lamp body adopts high-pressure cast aluminum and aluminum alloy, the surface is coated with outdoor used powder , double anti-corrosion to extend service life. This lawn lamp series uses LED. High efficiency constant current driver, ensure the light source is maximum used.
FIELDS OF APPLICATION
Factories, industrial production workshop, warehouse;
Gym, stadiums, golf courses,
Commercial establishments, overpasses, outdoor advertising board, landmarks;
Stage, yard, garden, lawn, park, plaza;
Supermarket, shopping mall, exhibition hall;
Ships, airports, subways, gas station, the train station, highway toll station, dock
Factory, office, meeting room, conference hall, storeroom, etc.
IP 65 IK 09 SMD McA Step 3 220~240V
5 0 S 0 4 - B - 3 0 - 6 0 - 0 - A
Model S04 |
5 0 S 0 4 - B - 3 0 - 6 0 - 0 - A |
||||
|
Size |
A Ø310 X 180mm |
B Ø380 X 210mm |
C Ø430 X 220mm |
D Ø480 X 230mm |
|
|
Driver |
0 On/Off |
1 Dali |
2 Dimmable |
3 Phase Dimming |
4 1-10 |
|
Beam Angle |
60° | 90° | 120° | ||
|
Kelvin |
30 3000K |
40 4000K |
50 5000K |
60 6000K |
|
|
Finishing |
White | Dark Grey | Black | ||
|
Wattage |
50 | 100 | 150 | 200 | 240 |
