U09
High Lumen Efficacy Body - Die Cast Aluminum Diffuser - PMMA lens Glowing Wire Test - 850° Temperature - ta=20 °C ~ ta max=50 °C Class - III
Used for 360° fountain jet lighting instead of bulky underwater floodlight.
The slim and fully sealed light provides the installer ease maintenance and installation.
IP 68 IK 10 SMD McA Step 3 DC 24V
2 4 U 0 9 - S S - 3 0 - 1 5 - 0 - A
Model U09 |
2 4 U 0 9 - S S - 3 0 - 1 5 - 0 - A |
||||
|
Size |
A 170 X 12mm |
||||
|
Driver |
0 On/Off |
1 Dali |
2 Dimmable |
3 Phase Dimming |
4 1-10 |
|
Beam Angle |
15° | 30° | 45° | 60° | |
|
Kelvin |
27 2700K |
65 6500K |
R RED |
G GREEN |
B BLUE |
|
Finishing |
SS316 | ||||
|
Wattage |
24 | 32 (Only RGB) | |||
